SS Side Flexing Chain Belt W190.5mm

$0.00

Applications

Industrial
Food
Cooling line

STRUCTURE :

Slat width (mm): 190.5

Hardness (HRC): 20

Min. side flexing radius (mm):500

Flatness (max) mm: 0.4

Working Load N (max): 5400

Weight: kg/m4.8

Material: Stainless Steel

Country of origin : Italy
